Filter Introduction
1. Keel material is galvanized steel wire, and the surface is painted with electrostatic spraying.( Supporting filter cotton and difficult to deform in large air volume or harsh environment)
2. Filter material is of high dust holding capacity, fire resistance, replaceable, and cost savings.
3. Aluminum alloy (electrostatic spray, beautiful appearance). Aluminum or galvanized sheet (high strength, corrosion resistance). Filter material is of high strength, high fire resistance, washing resistance, and long service life. The protective net is made of aluminum or galvanization.( Supporting filter cotton and difficult to deform in large air volume or harsh environment)
Product Application
Electronics,pharmaceutical, hospital,spraying.
Type | Outside Dimensions(mm) | Efficiency (％) | Rated Air Flow (m3/h) | Initial Resistance | Resistance Humidity (％) | Fireproofing class | |
(Pa) | InH2o | ||||||
Wave | 292*292*45 592*592*45 292*592*45 490*592*45 | 80-90％ (Arrestance) | 800 3200 1600 2700 | 40-50 | 0.16-0.2 | 100 | Class2 (UL-900-1996) |
Filter Structure
1. Filtering material：Medium - effect composite cotton.
2. Frame plate: galvanized frame, aluminum frame, stainless steel frame.
Filter Introduction
1. Keel material is galvanized steel wire, and the surface is painted with electrostatic spraying.( Supporting filter cotton and difficult to deform in large air volume or harsh environment)
2. Filter material is of high dust holding capacity, fire resistance, replaceable, and cost savings.
3. Aluminum alloy (electrostatic spray, beautiful appearance). Aluminum or galvanized sheet (high strength, corrosion resistance). Filter material is of high strength, high fire resistance, washing resistance, and long service life. The protective net is made of aluminum or galvanization.( Supporting filter cotton and difficult to deform in large air volume or harsh environment)
Product Application
Electronics,pharmaceutical, hospital,spraying.
Type | Outside Dimensions(mm) | Efficiency (％) | Rated Air Flow (m3/h) | Initial Resistance | Resistance Humidity (％) | Fireproofing class | |
(Pa) | InH2o | ||||||
Wave | 292*292*45 592*592*45 292*592*45 490*592*45 | 80-90％ (Arrestance) | 800 3200 1600 2700 | 40-50 | 0.16-0.2 | 100 | Class2 (UL-900-1996) |
Filter Structure
1. Filtering material：Medium - effect composite cotton.
2. Frame plate: galvanized frame, aluminum frame, stainless steel frame.
