Filter Introduction
1. Strong structure
2. Large filtering area
3. It is not easy to deform under the environment of large air volume and high humidity
4. Activated carbon antibacterial filter paper can effectively improve the IAQ
5. It can be Incinerated without pollution when abandoning.
6. SizeOEM
Type | Outside Dimensions(mm) | Efficiency (％) | Rated Air Flow (m3/h) | Initial Resistance | Resistance Humidity (％) | ||
(mm) | (inches) | (Pa) | InH2o | ||||
Paint stop filter | 592*592*45 287*592*45 490*592*45 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 65-80 | 0.26-0.32 | 100 |
1700 | |||||||
2800 | |||||||
592*592*22 287*592*22 490*592*22 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 95-110 | 0.38-0.44 | ||
1700 | |||||||
2800 | |||||||
592*592*98 287*592*98 490*592*98 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 65-75 | 0.26-0.3 | ||
1700 | |||||||
2800 | |||||||
Filter Structure
1. Filtering material：
2. Frame plate: galvanized frame, aluminum frame, stainless steel frame.
Filter Introduction
1. Strong structure
2. Large filtering area
3. It is not easy to deform under the environment of large air volume and high humidity
4. Activated carbon antibacterial filter paper can effectively improve the IAQ
5. It can be Incinerated without pollution when abandoning.
6. SizeOEM
Type | Outside Dimensions(mm) | Efficiency (％) | Rated Air Flow (m3/h) | Initial Resistance | Resistance Humidity (％) | ||
(mm) | (inches) | (Pa) | InH2o | ||||
Paint stop filter | 592*592*45 287*592*45 490*592*45 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 65-80 | 0.26-0.32 | 100 |
1700 | |||||||
2800 | |||||||
592*592*22 287*592*22 490*592*22 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 95-110 | 0.38-0.44 | ||
1700 | |||||||
2800 | |||||||
592*592*98 287*592*98 490*592*98 | 24*24*2 12*24*2 20*24*2 | 92％ (Arrestance) | 3400 | 65-75 | 0.26-0.3 | ||
1700 | |||||||
2800 | |||||||
Filter Structure
1. Filtering material：
2. Frame plate: galvanized frame, aluminum frame, stainless steel frame.
